The Aqua Medic Helix Max 2nd Generation destroys suspended algae and creates clear water in the aquarium. The water is guided spirally with long contact time on the quartz tube which ensures high efficiency of the UV-C light source. The UV radiation is used to the maximum. The inlet and outlet openings of the Helix Max can be rotated 360 °. This allows a space-saving and easy installation.
All Helix Max are equipped with a rubber cable and electronic high-frequency ballast for garden ponds, marine and freshwater aquariums. The electronic ballasts ensure a higher UV yield and longer life of the UV lamps
Product Features:
- Can eliminate single cell algaes giving crystal clear water in salt and fresh water aquaria.
- Helps eradicate bacteria and other water borne parasites and decreases the risk of fish acquiring infections.
- Controlled water flow and the large volume of the Helix Max 2.0 ensure maximum efficacy. The water is directed in a spiral path around the quartz tube resulting in more efficient use of the UV radiation than in standard units.
- The inlet fitting can be rotated by 360° for easy mounting at any angle. This allows a space-saving installation.
- Easy cleaning of the inner spiral by simple disassembly.
- Simple and safe function control through integrated viewing window.
- All versions of the Helix Max 2.0 are equipped with a high frequency electronic ballast for salt and fresh water aquaria. The electronic ballasts increase the lifetime and the efficacy of the UV lamps.
- Includes hose nozzles for connecting hoses.
Technical Data Helix Max 2.0 (9 Watts)
- Saltwater aquarium: up to 350L
- Recommended flow: 100-200 l/h
- Freshwater aquarium: up to 500 l
- Recommended flow: 100-500 l/h
- Power: 2.4 w/UVC
- Cable length: 3.5 m
- Lamp type: PL-S-9 W
- Max. pressure: 0.4 bar
- Water column max.: 2 m
- Power connection: 220-240 V / 50/60 Hz
- Housing dimensions without joints: 370xØ90mm (lxw)
Technical Data Helix Max 2.0 (11 Watts)
- Saltwater aquarium: up to 350L
- Recommended flow: 100-200 l/h
- Freshwater aquarium: up to 750 l
- Recommended flow: 300-800 l/h
- Power: 3.6 w/UVC
- Cable length: 3.5 m
- Lamp type: PL-S-11 W
- Max. pressure: 0.4 bar
- Water column max.: 2 m
- Power connection: 220-240 V / 50/60 Hz
- Housing dimensions without joints: 370xØ90mm (lxw)
Technical Data Helix Max 2.0 (18 Watts)
- Saltwater aquarium: up to 500L
- Recommended flow: 200-600 l/h
- Freshwater aquarium: up to 1,000l
- Recommended flow: 400-1,000 l/h
- Power: 5.8 w/UVC
- Cable length: 3.5 m
- Lamp type: PL-S-18 W
- Max. pressure: 0.4 bar
- Water column max.: 2 m
- Power connection: 220-240 V / 50/60 Hz
- Housing dimensions without joints: 380xØ110mm (lxw)
Technical Data Helix Max 2.0 (36 Watts)
- Saltwater aquarium: up to 1000L
- Recommended flow: 400-1,000 l/h
- Freshwater aquarium: up to 2,000 l
- Recommended flow: 500-1,500 l/h
- Power: 12 w/UVC
- Cable length: 3.5 m
- Lamp type: PL-S-36 W
- Max. pressure: 0.4 bar
- Water column max.: 2 m
- Power connection: 220-240 V / 50/60 Hz
- Housing dimensions without joints: 540xØ110mm (lxw)
Technical Data Helix Max 2.0 (55 Watts)
- Saltwater aquarium: up to 1500L
- Recommended flow: 600-1,500 l/h
- Freshwater aquarium: up to 3,000 l
- Recommended flow: 600-1,500 l/h
- Power: 18 w/UVC
- Cable length: 3.5 m
- Lamp type: PL-S-55 W
- Max. pressure: 0.4 bar
- Water column max.: 2 m
- Power connection: 220-240 V / 50/60 Hz
- Housing dimensions without joints: 695xØ110mm (lxw)
Specifications
| Brand | Aqua Medic |
